Model Specifications


Model SP300 HP450 HP600 HP1000
Machines Standard Flow High Flow High Flow High Flow
Operating Pressure 170-240 Bar 170-240 Bar 170-240 Bar 170-240 Bar
Hyd. Flow Required (Low Flow) N/A 83-106 lpm 83-106 lpm N/A
Hyd. Flow Required (Std Flow) 45-84 lpm 109-132 lpm 109-132 lpm N/A
Hyd. Flow Required (High Flow) N/A 136-166 lpm 136-166 lpm 136-166 lpm
Power Range (Low Flow) N/A 36-48 hp 36-48 hp N/A
Power Range (Std Flow) 25-33 hp 45-58 hp 48-58 hp N/A
Power Range (High Flow) N/A 60-71 hp 60-71 hp 60-71 hp
Overall Length 1110 mm 1277 mm 1277 mm 1277 mm
Overall Height 816 mm 878 mm 878 mm 878 mm
Overall Width 1320 mm 1776 mm 1776 mm 1776 mm
Planing Width 305 mm 457 mm 610 mm 1000 mm
Planing Depth 0-127 mm 0-127 mm 0-127 mm 0-127 mm
Drum Diameter 482 mm 560 mm 560 mm 560 mm
Weight 680 kg 997 kg 1088 kg 1406 kg
No.of Picks 37 45 57 89
Tilt 11°
Side-shift (Centre to Right) 0-482 mm -75-560 mm -75-560 mm -75-560 mm

(*) Available on extended lead times.
