digga bigfoot-xd-trencher Goulburn - Goulburn Farm Machinery

Trencher Bigfoot-XD

First Name*

This field is required

Last Name*

This field is required

Phone Number*

This field is required Not a valid number!

Email Address*

This field is required This is not a valid email.

Questions/Comments

This field is requiredValidating ....Captcha confirmation text is invalid

For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.

BIGFOOT XD TRENCHER GALLERY

Click on the images below to enlarge.

Specifications	900	1200	1200 HF	1500 HF
Rec Flow Range	150 / 200 / 250 / 300 mm	150 / 200 / 250 / 300 mm	150 / 200 / 250 / 300 mm	150 / 200 / 250 / 300 mm
Foot Depth Presets	450 / 600 / 750 / 900 mm	600 / 800 / 1000 / 1200 mm	600 / 800 / 1000 / 1200 mm	750 / 1000 / 1250 / 1500 mm
Hydraulic Flow	60-115 lpm	60-115 lpm	105-170 lpm	105-170 lpm
Motor Size	2K Bell EATON	2K Bell EATON	2K Bell EATON	2K Bell EATON
Max Pressure - Do not exceed	240 bar @ 60 lpm	240 bar @ 60 lpm	240 bar @ 60 lpm	240 bar @ 60 lpm
Max Flow - Do not exceed	95 lpm @ 200 bar	95 lpm @ 200 bar	170 lpm @ 180 bar	170 lpm @ 180 bar
Max Continuous Power	25 Kw (34 hp)	25 Kw (34 hp)	50 Kw (67 hp)	50 Kw (67 hp)
Length	2225 mm	2532 mm	2532 mm	2689 mm
Horizontal Height	777 mm	777 mm	777 mm	836 mm
Width	1212 mm	1212 mm	1212 mm	1138 mm
Weight - With a 150mm Combo Chain	388 kg	405 kg	424 kg	461 kg

Australia's leading machinery attachment manufacturer est. 1981
